LiteGear DMX Dimmer Pack, E-Control 6x6
Day Rate: $ 11.25
Quantity | Add/Remove |
E-Control 6×6-V2 is one of LiteGear’s economical DMX decoders. Its light weight and low profile lends itself to being built into nearly any rig in which DMX control is required. The 6×6-V2 is adaptable to a number of situations, allowing for the control of multicolor red-green-blue-amber-tungsten-daylite (RGBATD) LED rigs in addition to one circuit of RGBA/W LiteRibbon®, two circuits of RGB LiteRibbon, three circuits of Hybrid LiteRibbon, and six circuits of Single LiteRibbon.
SIZE: 7 × 3 × 1.5 in
WEIGHT: 0.57 lb
INPUT: 12V/24V DC; Input voltage must match load voltage requirements!
OUTPUT: PWM RATING: 6A max. per channel x 6 channels
DATA-IN: RJ45
CONNECTOR OUT: Bare wires
WEIGHT: 0.57 lb
INPUT: 12V/24V DC; Input voltage must match load voltage requirements!
OUTPUT: PWM RATING: 6A max. per channel x 6 channels
DATA-IN: RJ45
CONNECTOR OUT: Bare wires
